DT VERSA
More Than a Copy Stand
The DT Versa is a complete digitization platform. The stand, camera, and column seamlessly integrate with our software for fast and easy preservation-grade digitization. The Versa allows digitization with or without glass contact.
Conservation Friendly
With the Versa in place, all scanning is done 100% contact-free. Removing that hard top reveals a conservation-friendly glass top with a user-settable maximum and with such precise control of the object that the operator can raise the object to lightly kiss the glass.
Scan Anything
Nearly anything can be scanned with the DT Versa. Bound materials are its raison d’être, but it’s equally at home scanning manuscripts, flat artwork, maps, translucent materials such as film or glass plate negatives, as well as specimens.
Standards Compliant
Our DT Versa complies with FADGI 4-star, Metamorfoze Strict, and ISO 19264 Level A image quality standards, as well as JHOVE file format standards. Institutions such as The Library of Congress, The National Archives, and Getty trust our systems to provide the ultimate image quality.
Open Platform
While our camera and software offer simplicity, quality, and throughput, the Versa accepts any camera. You can purchase a Versa on one budget cycle and our camera on the next, or upgrade the camera anytime.
Solid, Precise, and Perfectly Aligned
The bench is made in the USA to 0.005” tolerances from aerospace grade aluminum. The DT AutoColumn precisely positions the camera within two-hundredths of an inch, and the Phase One iX camera platform enables focus movement in microns for meticulous accuracy.
Help at Every Step
We treat our valued customers as partners – our highly trained staff are ready to meet your individual institution’s needs. Every system includes on-site training and unlimited support! Plus, our warranty packages are determined with your sales representative, uniquely reflect the items in your system, and never require a service contract. If you’re starting or revamping a digitization program, see our program planning guide and reach out; we’re glad to help!
Image Quality • Object Safety • Productivity
Bench
Solid, precise, laser aligned
Made in USA
3-Year warranty
Column
Smooth, precise movement
Droop-free camera arm
Anti-vibration pendulum
Camera
iXG and iXH: complete integration
RCam: ultimate flexibility
Or bring your own camera
Software
AutoCrop & Deskew
AutoPPI column integration
Fast and modern interface
Customization & Accessories
Customization
Custom Table Surface
Custom Column Height
Column Wall Mount
Lighting
DT Photon XL LED
Profoto Strobes
Broncolor Strobes
Material Handling
Book Wedge
V-Cradle
Film Scanning Kit
Vacuum Board
Standards Verification
Golden Thread Software
ISA Reflective Targets
ISA Film Scanning Targets
Specifications & Features
Don’t see a specification you need? Contact us.
BENCH
Materials: Black-anodized aerospace-grade aluminum
Glass Mode: Two 16½” x 27½” (41 cm x 69 cm) platforms with independent pressure-controlled lift with up to 4″ (10 cm)gutter gap.
Glass-Free Mode: Removable 40″ x 30″ (101 cm x 76 cm) laminated copyboard
Footprint: 40.4″ by 42.0″ (1.1 m x 1.1m)
Work deck height: 30″
Height: 102.4″(customizable)
Feet: 4 vibration-dampening casters for leveling system and portability
COMPRESSOR
Type: 0.5 HP, 6.3 gal tank
Power: 115V / 50-60Hz. 220V compressor also available.
Noise: Intermediately 60dB. Otherwise none.
Notes: House air can be used in lieu of compressor.
SOFTWARE
Name: Capture One Cultural Heritage Edition (aka Capture One CH)
Features: AutoCrop and AutoDeskew, Film Negative inversion, multiple derivative output
COLUMN
Camera Mount: Arca dovetail
Operation: From Capture One CH using USB or manually using remote
AutoPPI Mode: Using Capture One CH you can set the camera height by entering the desired capture PPI
Movement: 0.01″ precision using Capture One CH. Fast/slow modes.
Mounting: Integrated into DT Versa or Wall-Mounted
Stability: antivibration pendulum included; wall-anchor optional
Power: 110/220 volt autoswitching. Accepts any standard “computer power” plug for easy international use.
CAMERA: iXG or iXH
Resolution: 100 or 150MP
PPI: See PPI Explanation
Focusing: Linear-motor for no-slip high-precision focusing while pointed downward. Manual or automatic focusing via Capture One CH.
Shutter: Precision electronically controlled shutter with max speed of 1/250th and 1 million capture warranty.
Mount: Integrated L-Bracket with 3/8th threads and dovetail
Weight: 5 lbs w/ 72mm Mk I lens
Size: 5.9″ x 4.7″ x 3.9″ at infinity
CAMERA: DT RCam
Resolution: 50, 60, 80, 100, and 150MP
PPI: See PPI Explanation
Focusing: No-slip precision helical with 20mm of travel and optional lock.
Shutter: Precision electronically controlled shutter with max speed of 1/250th and 1 million capture warranty.
Mount: Integrated L-Bracket with 3/8th threads and dovetail
Weight: 4 lbs 15 oz (body only)
Size: 6″ diameter, 3.05″ depth
Lenses: Schneider 72mm Digitar & Schneider 120mm APO Digitar.
