One Robust System

The Phase One iXG Camera System: A purpose built camera system designed for use in Cultural Heritage production environments and other industrial application. This system is rugged, built to last and made for serious high production needs where DSLR’s just will not cut it.

With an all in one integrated design, the iXG can handle any situation or need while providing the operator with almost full software control over every feature.

Color Accuracy & Superior Detail

The iXG Camera System uses CMOS sensors in both the iXG 100MP and iXG 50MP models to ensure the highest resolution and lowest noise levels. These sensors produce the most accurate colors and minute details, enabling accurate reproduction for any cultural heritage applications. The degree of detail, quality and accuracy of color is crucial for the accurate reproduction of rare books, artworks, documents and more.

The iXG 100MP Achromatic model uses the all new 100MP Achromatic sensor, combining the highest possible resolution and class-leading wide spectrum sensitivity that are needed for specialized applications such as multi-spectral and NIR (Near Infra-Red) imaging.

Capture One CH Software Integration

Full integration of the iXG with Capture One Cultural Heritage software gives the operator an efficient professional workflow and with more precise results. Initially the iXG provides remote operation of focus with symmetrical up/down response even when pointed straight down on a copy stand, as well as ultra-accurate one-click contrast-based autofocus. Shutter control is integrated directly into Capture One CH. We have very exciting plans for additional integration that will radically simplify the copy stand digitization workflow; check back soon for more details, or talk to your DT Heritage sales person.



Schneider Kreuznach Optics

The iXG Camera utilizes integrated Flat Field Optics with the 72mm and 120mm Schneider Kreuznach lenses. This compatibility addresses the needs of flat copy work, particularly useful for libraries, archives, and universities, for example. The Schneider Kreuznach lens design in combination with the digital lens perfection of Capture One CH, offers the highest quality in terms of resolution, flatness, sharpness, distortion and color required for the most demanding reproduction applications.

The iXG on a DT Heritage copy stand capturing 35mm color film.

Scientific Tools

The iXG Camera System is designed to be an open platform for new accessories needed for imaging applications by both existing and new customer segments. For example, with the addition of accessory lighting and filtering, the wide spectrum, infrared, and multi-spectral capabilities of the iXG meet the highest standards required. These iXG capabilities also open the door to sequential imaging and computational imaging, required for both multi-spectral and 3D applications.

Precision Focus Control

With the iXG Camera System you get precise, accurate and smooth motor driven focusing. Position-recording of the lens and camera ensures optimum focus accuracy. Precision focus control with both manual and preset positioning, and contrast-based autofocus sets distance and resolution parameters accurately and reliably. This paves the way for automated setting up of camera position and focus for a specific job in terms of document size and capture resolution.

Support from DT

With offices in New York and LA, and a team of 17 professionals located in five states we are devoted to providing top quality service to our customers. We have been a partner with Phase One since our opening day more than 13 years ago and have had a global partnership starting in 2013 to bring DT Heritage digitization equipment to the world. Digital Transitions at large has also been the #1 source for Phase One digital backs, bodies and lenses in the US and was awarded Support Partner of the Year in 2015.

iXG CAMERA SYSTEMS

Technical Specifications Comparison

iXH 150

iXG 100

iXG 100 WS

iXG 50

Pixel Count 150MP 100MP 100MP 50MP
Sensor Size 53.7 x 40.4 mm 53.7 x 40.4 mm 53.7 x 40.4 mm 53.7 x 40.4 mm
Pixel Size 3.76 μm 4.6 μm 4.6 μm 5.3 μm
Resolution 14,204 x 10,652 8,708 x 11,608 8,708 x 11,608 6,208 x 8,280
ISO Range 50 – 800 50 – 800 50 – 6400 50 – 800
Shutter types Leaf, electric Leaf, electric Leaf, electric Leaf, electric
Shutter Speed Leaf: 1/250 – 30 sec
Electronic: 1/4,000 – 1 hour
Leaf: 1/250 – 30 sec
Electronic: 1/250 – 1 hour
Leaf: 1/250 – 30 sec
Electronic: 1/250 – 1 hour
Leaf: 1/250 – 30 sec
Electronic: 1/250 – 1 hour
File Formats IQL 16 bit raw
IQS 16 bit raw compressed
IQL 14 bit raw
IQS 14 bit raw compressed
IQL 16 bit raw
IQL 14 bit raw
IQS 14 bit raw compressed
Raw 16 bit
Raw 14 bit
IQL 16 bit raw
IQL 14 bit raw
IQS 14 bit raw compressed
Connectivity USB-C, 10G ethernet USB 3.0, HDMI USB 3.0, HDMI USB 3.0, HDMI
Storage Tether to PC Tether to PC Tether to PC Tether to PC
Weight 3450g / 7.61 lbs
w/ 72mm Mk II and L-Bracket
3350g / 7.4 lbs
w/ 72 Mk II and L-Bracket
2300g / 5 lbs
w/ 72 Mk I and L-Bracket
2300g / 5 lbs
w/ 72 Mk I and L-Bracket
Dimensions 227 x 130 x 130 mm
Including 72 Mk II and L-bracket
227 x 130 x 130 mm
Including 72 Mk II and L-bracket
150 x 130 x 130 mm
Including 72 Mk I and L-bracket
150 x 130 x 130 mm
Including 72 Mk I and L-bracket
Cooling Integrated heat sink & fans Integrated heat sink & fans Integrated heat sink & fans Integrated heat sink & fans
Approvals FCC Class A, CE, RoHS FCC Class A, CE, RoHS FCC Class A, CE, RoHS FCC Class A, CE, RoHS
Operating Temp 50º – 95º F 50º – 95º F 50º – 95º F 50º – 95º F
Operating Humidity 15 – 80% (non-condensing) 15 – 80% (non-condensing) 15 – 80% (non-condensing) 15 – 80% (non-condensing)

iXG CAMERA SYSTEM PRODUCT IMAGES
