The Largest Modern Copy Stand

The DT Titan is a complete digitization platform. The stand, camera, and column tightly integrate with our software for fast and easy preservation-grade digitization.

For Every Material Need

Digitizing large material presents a unique challenge to most typical copy stands. From historical maps and oversized artworks, to textiles and elephant folios, finding a surface to support the subject, as well as getting the entire piece in the image sensor’s field of view, can be a struggle. With those specific needs in mind, DT has created our largest digitization system – the DT Titan

Industry-Leading Design

This is the Heritage industry’s first 40” x 60” digitization system that features the same level of precision, robustness, and workflow integration as the rest of DT’s product line. And because it’s part of DT’s existing digitization ecosystem, it’s also compatible with your current workflows, training, and camera systems, making it easy to swap between your existing DT systems without any additional effort or expense.

Solid, Precise, and Perfectly Aligned

The DT Titan also features the DT AutoColumn XXL, our tallest automated photo column, which can be controlled from both a remote and from within Capture One CH. This intelligently- controlled column integrates directly with the Phase One iXG and Phase One iXH cameras to provide AutoPPI, allowing the user to set the camera position and focus to a given PPI with one click. This level of integration and automation means you won’t have to break out a ladder to futz with the camera, change a battery, or focus a lens – control entirely from the computer is safer for the material, and safer for the operator.

Built To Handle Your Largest Materials

To aid with the challenge of handling over-sized materials, an optional multi-gated vacuum table can be selected, which is also compatible with the direct or indirect use of magnets to hold down especially difficult materials. Indirect magnet use typically involves mylar straps or filaments held in place using magnets, allowing them to be rapidly repositioned and tensioned without magnets actually contacting the material itself.
DT Versa - Open Platform

Tailored To Your Workflows

As with any DT digitization system, we work with each client’s unique needs and workflow to select the appropriate lighting solution, cameras system, software, and service/support/training to ensure the DT Titan integrates seamlessly into your institution’s workflow.
DT Versa - Open Platform

Help At Every Step

We treat our valued customers as partners – our highly trained staff are ready to meet your individual institution’s needs. Every system includes on-site training and unlimited support! Plus, our warranty packages are determined with your sales representative, uniquely reflect the items in your system, and never require a service contract. If you’re starting or revamping a digitization program, see our program planning guide and reach out; we’re glad to help!


DT Versa - Open Platform

Image Quality  •  Object Safety  •  Productivity

Customization  &  Available Accessories


Large 40″ x 60″ Surface
Solid, precise, laser aligned
Made in USA
3-Year warranty



DT AutoColumn XXL
Smooth, precise movement
Droop-free camera arm
Anti-vibration pendulum



iXG or iXH: complete integration
RCam: ultimate flexibility
Or bring your own camera


AutoCrop & Deskew
AutoPPI column integration
Fast and modern interface

Specifications & Features

Don’t see a specification you need? Contact us.


Materials: Black-anodized aerospace-grade aluminum

Foot Print: 53.25” x 60” Standard | 53.25 x 63” with optional Vacuum Top

Table Surface: 40″ x 60″ at 30″ working height (customizable)

Height: 131” (Customizable as-needed)

Feet: 4 vibration-dampening casters for leveling system and portability


Name: Capture One Cultural Heritage Edition (aka Capture One CH)

Features: AutoCrop and AutoDeskew, Film Negative inversion, multiple derivative output



Camera Mount: Arca dovetail

Operation: From Capture One CH using USB or manually using remote

AutoPPI Mode: Using Capture One CH you can set the camera height by entering the desired capture PPI

Movement: 0.01″ precision using Capture One CH. Fast/slow modes.

Mounting: Integrated into DT Titan or Wall-Mounted

Stability: antivibration pendulum included; wall-anchor optional

Power: 110/220 volt autoswitching. Accepts any standard “computer power” plug for easy international use.



Resolution: 100mp, 150mp

PPI: See PPI Explanation

Focusing: Linear-motor for no-slip high-precision focusing while pointed downward. Manual or automatic focusing via Capture One CH.

Shutter: Precision electronically controlled shutter with max speed of 1/250th and 1 million capture warranty.

Mount: Integrated L-Bracket with 3/8th threads and dovetail

Weight: 5 lbs w/ 72mm Mk I lens

Size: 5.9″ x 4.7″ x 3.9″ at infinity



Resolution: 50, 60, 80, 100, and 150mp

PPI: See PPI Explanation

Focusing: No-slip precision helical with 20mm of travel and optional lock.

Shutter: Precision electronically controlled shutter with max speed of 1/250th and 1 million capture warranty.

Mount: Integrated L-Bracket with 3/8th threads and dovetail

Weight: 4 lbs 15 oz (body only)

Size: 6″ diameter, 3.05″ depth

Lenses: Schneider 72mm Digitar & Schneider 120mm APO Digitar.
